Indicators

UCC3843

UCC6403

Detector Type

Vanadium Oxide

Resolution

384×288

640×512

Pixel  Size

12μm

Frame Rate

≤60Hz

Spectral Range

8～14μm (LWIR)

NETD

≤40mK（@F/1.0, 50Hz, 300K）

Image frame rate

25Hz/50Hz

Image Function

Image Adjustment

Indoor/outdoor/manual

Image Mode

Linear mode,normal temperature mode,low temperature

mode,high temperature mode

Color Palettes

White Hot, Black Hot, Iron, Iron invert, Rainbow, Red Hot, Feather,

Spring Feather, Lava, Amber, Iron Ash, Black Blue, Blue Red, Multi, RGB

invert

E-Zoom

X1 、X2 、X4 、X8

Image Processing

NUC, Filter Noise,Detail Enhancement

Image Mirror

Right and Left, Up and Down

Power

Power Protection

Support Overvoltage, Undervoltage and Reverse Polarity Protection

Power supply

5-12VDC

Power Consumption

≤1W

Interface Options

Analog Video(Standard)

CVBS

Digital Video(Optional)

USB（ UVC） 、BT.656

Communication Interface

RS-232/UART232,RS422/RS485

Physics Parameters

Weight

≤23g（without lens and connector)

Dimension

26×26×21.1mm（without lens and connector)

Lens

Lens

25mm Lens（ Standard）

6mm/9mm/13mm/19mm/25mm/35mm/50mm/75mm(Option)

FOV

6mm

44°×33°

73.4°×58.7°

9mm

29.3°×22°

48.9°×39.1°

13mm

20.3°×15.2°

33.9°×27.1°

19mm

13.9°×10.4°

23.2°×18.5°

25mm

10.6°×7.9°

17.6°×14.1°

35mm

7.5°×5.7°

12.6°×10.1°

50mm

5.3°×4.0°

8.8°×7.0°

75mm

3.5°×2.6°

5.9°×4.7°

Environment Parameters

Operating Temperature

-40℃ ~ 80℃

Storage Temperature

-45℃ ~ +85℃

Humidity

5～95%，non-condensing

Vibration

6.06g，All Axial for Random Vibration

Shock

40g，4ms，Rear Peak Sawtooth Wave at 3 Axes of  6 Directions
